THREADED RODS

We at STEEL OILFIELD SUPPLIES are one of the renowned manufacturer, exporter, stockist, stock holder and supplier of a qualitative range of Threaded Rods Fastener that are being designed as per the national and international standard quality of raw materials. These treaded rods are fabricated from the best quality base materials such as stainless steel so that they become doubly endurable and long lasing in nature. They have high tensile strengths that resist them from any abrasion for a longer period of time. These Threaded Rods are known amidst our clients for their resistance to corrosion and high durability.

Buy now Stainless Steel Threaded Rod and Hollow Threaded Bar at low cost

Meanwhile, to meet the quality conscious requirements for our highly esteemed clients, we provide these Threaded Rods in different sizes, grades and thickness as per customized requirements given by our customers.

Table of Content

  • Specification Of Stainless Steel Threaded Rod
  • Types Of Threaded Bar
  • Galvanized Threaded Rod Dimension chart
  • Weight of M10 Threaded Rod
  • Ready Stock of All Thread Rod
  • Before choosing your supplier check our deliveries of last 2 years

Specification Of Stainless Steel Threaded Rod

Standard : DIN975 , ASTM A307, DIN, ASTM, BS and all International Standards

Size : M6 to M52 & 1/4" to 2"

Length : up to 6m long

Grade : 4.8, 6.8, 8.8 . 10.9, SS304 , SS316 & ASTM A307, ASTM 193 B7, B8 & B8M Finish : Zinc Plated , Plain , Hot Dip Galv. & Yellow Zinc

Type : Threaded Rods

Threaded Rod DIN Standard B.S. DIN 933, DIN 931, DIN 934, DIN 912, DIN 603, DIN 6923, DIN 970, DIN 7981, DIN 7982, DIN916, DIN 913, DIN 7985
ISO – International Organization for Standardization ISO 4032, ISO 4033, ISO 4017, ISO7380 JIS standards
UTS – Unified Thread Standard UNC, UNF, UNEF, UNS, NPT, NPTF
Threaded Rod Grade 304 Stainless Steel
SS 304
18-8 Stainless Steel
A2 Stainless Steel
Type 304 Stainless Steel
DIN 939
Stainless Steel
A2 Stainless Steel Class A2 70
A2-80
A2-50
British standards BS EN ISO 3506, DIN 976-1 A2 STAINLESS STEEL
Stainless Steel Threaded Rod Size
  • Cold Froging : M2-M24
  • Hot forging M24-M100, 1-1/2” Dia, up to 1100mm lg
  • Machining and CNC for Customized connecting element: up to M100 / 4” Dia, up to 1500mm lg

304 Stainless Steel Threaded Rod M2, M3, (M3.5), M4, M5, M6, M8, M10, M12, (M14), M16, (M18), M20, (M22), M24, (M27), M30, M33, M36, M42, (M45), M48 to M160 and Custom Sizes
Threaded Rod Length up to 6m long
Diameter 2 mm-50  mm
Height 145  mm
Stainless Steel Threaded Rod Threads: METRIC, BSW, BSF, UNC, UNF or as required
Standard:

DIN, ISO, JIS, GB, IS, BS, ASTM and all International Standards
ANSI – American National Standards Institute

  • ANSI B 18.2.4 2M
  • ANSI B 28.2.4 1M
  • Stud Bolt length are defined in ASME B16.5 standard
  • Hex nuts are defined in ASME B18.2.2
  • ASME B18.5
  • GB/T5782, GB/T5783, GB5783
Threaded Rod Dimensions ASME B18.6.3 **Exception: screws 6 inches and shorter are fully threaded.
Tolerance +/-0.01mm to +/-0.05mm
Head drive: Phillips, Slotted, Phillips/Slot, Six-Lobe, etc
Threaded Rod Finishing: Zinc (yellow, white, blue, black), black oxide,
Geometry, Dacroment, anodizing, nickel plated, plated zinc-nickel, Stainless steel: Passivated
Self-Colour, Hot Dip Galvanised (HDG), Bright Zinc Plated (BZP), Sherardized, Stainless Steel, Mechanically Applied coating and some special one like DACROMET
Finish Per ASTM A380/A380M
Production process

Wire Drawing, Cold Heading, Insert tapping, Heat Treatment, Surface Plating, Inspection, Packing
Threaded Rod materials Surface Coating:
  • Hot Dipped Galvanizing
  • Phosphate
  • Teflon
  • Ptfe Coated
  • Xylon
  • Zinc Phosphate
  • Manganese Phosphate
  • Zinc Electro Plating (Hexavalent or Trivalent Chrome)
  • ZAC (Zinc Alluminium Flake Coating)
  • Cadmium

All surface finishes can be supplied, including Zinc, Galvanised, Sherardized, Electroless Nickel, Dacromet, Geomet & PTFE.
Threaded Rod Surface treatment
  • Passivation
  • Polish
  • Anodizing
  • Sand blasting
  • Electroplating (color, blue, white, black zinc, Ni, Cr, tin, copper, silver)
  • Black oxide coating
  • Heat-disposing
  • Hot-dip galvanizing
  • Rust preventive oil
Top Manufacturers SPAX® Screws, GKW, Unbrako, Kundan, APL, Sundaram Precision, Infasco, EBY Fastener Etc.
304 Stainless Steel Threaded Rod Packing: IN BULK: canton, pallet, Small Boxs / carton / pallet, or customer request
Why choose us?
  • Best Price in India and compare to China
  • Professional technical team
  • High precision threads
  • Strong production line
  • Micro Metals will be your reliable partner
Threaded Rod Test Certificate:
  • Manufacturer Test Certificate as per EN 10204 / 3.1,
  • Tensile testing to ISO 898-1
  • Nut proof load testing to ISO 898-2
  • Suitability for preloading to EN 14399-2
  • Suitability test for calibrated preload to EN 14399-10
  • Charpy Impact testing in accordance with ISO 148-1
  • Hardness testing to ISO 6508-1
  • Tri-Roll Thread Comparators
  • Calibrated gauges and tools
Threaded Rod Uses & application Railway, Wind tower, Secure suspended ceilings,Nuclear power, Automotive industry, Construction, Electronic industry

Galvanized Threaded Rod Dimension chart

Thread
Weight per metre
Strength
Class 70
Class 80
0.2% proof
UTS
0.2% proof
UTS
Kg/m
kN
kN
kN
kN
M12
0.72
41.0
64.0
54.0
73.0
M16
1.31
70.7
109.9
94.2
125.6
M20
2.05
110.3
171.5
147.0
196.0
M24
2.96
158.9
247.1
211.8
282.4
M27
3.83
206.6
321.3
275.4
367.2
M30
4.70
252.6
392.7
336.6
448.8
M33
5.78
312.3
485.8
416.4
555.2
M36
6.84
367.7
571.9
490.2
653.6
M39
8.14
439.2
683.2
585.6
780.8
M42
9.38
504.5
784.7
672.6
896.6
M45
10.90
587.7
914.2
783.6
1044.8
M48
12.32
662.9
1031.1
883.8
1178.4
M52
14.65
791.1
1230.6
1054.8
1406.4

Weight of M10 Threaded Rod

Do not forget to compare our price and quality with other Stainless Threaded Rod manufacturers, get best deal on all sizes of 14mm Threaded Rod, 2 Inch Threaded Rod

Size
Wt Per 100′
Pieces Per Tube
1/4-20
12.3
50
5/16-18
20.1
35
3/8-16
29.6
25
7/16-14
40.6
17
1/2-13
53.9
12
9/16-12
67.6
10
5/8-11
85.2
8
3/4-10
124.9
5
7/8-9
172.4
4
1-8
225.6
2
1 1/8-7
284.2
1
1 1/8-8
290.9
1
1 1/4-7
357.6
1
1 1/4-8
365.8
1
1 1/2-6
517.8
1
1 1/2-8
539.7
1
1 3/4-5
703.0
1
2″-4 1/2
922.0
1
